100% Nylon filter mesh JPP56 White nylon mesh nylon filter fabric

Categories Nylon Mesh
Brand Name: SPRING
Model Number: JPP
Certification: ISO9001
Place of Origin: Shanghai China
MOQ: 30m
Price: 0.8-2.6$/m
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000m/day
Delivery Time: 3-5 work days
Packaging Details: Waterproof plastic,Bubble bag,carton,Woven bag,Packing belt.210cm*25cm*25cm,185cm*33cm*33cm,55cm*45cm*45cm
Material: Nylon
Color: White
Width: 0.1m-3.8m
HS Code: 5911200090
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

100% Nylon filter mesh JPP56 White nylon mesh nylon filter fabric

Nylon filter mesh JPP56 White nylon mesh nylon filter fabric

Filtration rates can be from 27% to 78%. Such as food industry for milling filtering and flour milling, milling and other grains milling. Like glucose production, milk powder, soybean milk etc.

filter mesh Mesh opening:25micron-2000micron

The Filtration Division of SPRING not only designs and produces precision woven fabrics but has the ability to engineer them into finished or partly finished products. Our specially designed processing equipment together with our experience and expertise enables us to provide fabrics cut to size and high quality custom fabricated parts, in almost any requested shape.

Filteration: Widely used in areas as filtration and separation industry,the industries of petroleum, chemical, metallurgy, cement, environmental dedusting and mine. filter mesh.

Some examples of our fabrication capabilities are:

Ultrasonic Plotting, Stamping and Shaping – These processes are ideal for low volume, high tolerance parts that require completely sealed edges.

Sewing – We can supply a wide range of sewn products (bags, sleeves and belts) and many edging, joining and reinforcing solutions.

Ultrasonic sealing

Pleating

Heat slitting – single or multi-layer ribbons are slit with heat to provide an even sealed edge.

Ultrasonic slitting – fabrics can be slit into ribbons or welded into single or doubled seamed tubes.

Tubing – tubes can be cut to length and sealed to close one end.

Cold stamping – high volume parts can be cut to any size or shape.

Filter Mesh,nylon mesh,filter cloth,Nylon Filter Mesh,Nylon Fabric.

TypeMesh Count (/cm)Mesh Count (/inch)Thread Diameter(um)Mesh Opening(um)Open Area(%)Thickness (um)
JPP 44105501950611020
JPP 5513400160064760
JPP 5513500150056940
JPP 6615350131762680
JPP 6615400126758780
JPP 7718350107957675
JPP 882030095058585
JPP 882035090052685
JPP 992425086160465
JPP 10102530070049576
JPP 12123025058349470
JPP 12123030053341585
JPP 14143520051452375
JPP 16164020042546380
JPP 18184520035641385
JPP 20205015035049375
JPP 20205020030036385
JPP 24246015026741285
JPP 28287012023744215
JPP 30307612021341225
JPP 32328010021346170
JPP 36369010017841180
JPP 404010010015036190
JPP 43431108015343135
JPP 48481208012838145
JPP 5656142601194496
JPP 59591506010942102
JPP 6464163609638108
JPP 727218350894188
JPP 808020350753692
JPP 909023043683870
JPP 10010025443573272
JPP 11011028043482876
JPP 12012030543402378
JPP 13013033043341980
JPP 14014035538332275
Remark: These are theoretical data for reference only.
Mesh Opening & Open Area only slight error according to actual data.
