Long Distance Drone Frequency Scrambler Customized With 24 Hours Working Time

Categories Drone Signal Jammer
Brand Name: TSL
Model Number: TSL-PDJ
Certification: ISO9001, SGS, FCC, ROSH
Place of Origin: China
MOQ: 1 Piece
Price: negotiation
Payment Terms: T/T Bank Transfer, , PayPal
Supply Ability: 1000pcs per month
Delivery Time: 1 Working Day
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Product Name: Drone Camera Jammer
Application: UVA Remote Control Jamming
Protection: IP65
RF output power: 50 watts each band
Gross Weight: 45 kgs
Working time: 24 hours
Operating Temp: -20 to 60℃
OEM / ODM: available
Jammer type: High Power Outdoor Drone Jammer
Jamming Range: 5000m
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Long Distance Drone Frequency Scrambler Customized With 24 Hours Working Time

Long Distance Drone Camera Jammer UVA Remote Control Jammer

Drone Defense Control System is the latest drone control system with more than 5000 meters jamming distance that can block remote control signal, figure transmission signal and positioning signal. It can make the drone communication failure and forcing the drone to fall or return.



Suitable places


Government buildings, prisons, airports, scientific research centers, power plants, nuclear power plants, water control center, military and any other places where the unknown UAV drones are not welcomed.


Drone Jammer system features

  • Ultra-high power coverage can be used to shielding all UAV drones
  • Frequencies and power can be customized
  • Five channels can be adjusted independently
  • Fault alarm function
  • Intelligent control system, modular configuration upgrade for convenient maintenance.
  • High heat-cast aluminum chassis ( Protection degree IP65 )

Technical parameters

ItemChannelFrequency(MHZ)Output Power(dBm)Channel Output Power

Waveband

Optional

CH1922-9274735dBm/30KHZ(min)
CH21180-12804730dBm/30KHZ(min)
CH31550-16204732dBm/30KHZ(min)
CH42400-24864734dBm/30KHZ(min)
CH55725-58504327dBm/30KHZ(min)
Interference Distance500-2000m 14dbi Directional antenna
Temperature-40℃ ~85℃
Humidity30%-95%
Power SupplyAC-220V/DC-28V Power consumption:700W

All kinds of 360 degree digital drone jammer for prison can be customized

UAV drones are becoming a nuisance and can compromise your privacy as they are becoming cheaper every day and more easy to get. We carry a specialized range of jammers designed to distupt remote control (RC) of a drone / quadcopter and its gps signal. By this most of them will automatically slowly ground itself. Drones can be more than just an annoyance. Because they can reach high into the air, on the ground and in the water. UAV drones literally add a new dimension to eavesdropping and spying on facilities, individuals and infrastructures in a wide variety of environments and industries. They have the power to shrink the realm of public safety, privacy and physical security. Few other technologies have such power. Are drones spying on you? Stealing your top secrets? Watching your movements? Exposing your contacts? Drone laws remain ambiguous worldwide and it will take governments years to set limits on the ways in which drones can be used. Drones can even be used as a explosives carrier or as a terrorist propaganda on a mayor aired sports and cultural events.


Eight frequency Drone jammer specification (customized frequencies)
NO.specificationRequirementRemarks
1Frequency400~500MHz
930~960MHzGSM900
1805~1880MHzGSM1800+LTE1800
2110~2170MHzWCDMA2100
1574~1577MHz1.5G-GPS
1597~1607MHz1.5G-GLONASS
2400~2484MHz2.4G RC
5725~5850MHz5.8G RC
2Jamming sourceDual digital jamming source
3Power≥45dBm 400~500MHz
Device Port Output Power
≥45dBm 930~960MHz
≥43dBmX2 1805~1880MHz
≥43dBmX2 2110~2170MHz
≥40dBm 1574~1577MHz
≥40dBm 1597~1607MHz
≥40dBmX2 2400~2484MHz
≥35dBm 5725~5850MHz
4Effective jamming distance≥500M 400~500MHz
The drone was 100 meters high
≥500M 930~960MHz
≥500M 1805~1880MHz
≥500M 2110~2170MHz
≥1200M 1574~1577MHz
≥1200M 1597~1607MHz
≥3000M 2400~2484MHz
≥2500M 5725~5850MHz
5AntennasYagi antenna 400~500MHzFor:400~500MHz
Log periodic antenna 800~2500MHzFor:930~960MHz,1805~1880MHz,2110~2170MHz,1574~1577MHz,1597~1607MHz,2400~2484MHz
Antenna 1800~2500MHzFor:1805~1880MHz,2110~2170MHz,2400~2484MHz
panel directional antenna 5725~5850MHzFor:5725~5850MHz
6
Boot initialization time
15 seconds
Power supply
Built-in polymer lithium battery
8Endurance1.0 hours(25°C)
9
waterproof level
Anti-rain IP 65
10Working temperature-25~55°C
Cheap Long Distance Drone Frequency Scrambler Customized With 24 Hours Working Time for sale
