433 MHz Manpack Trolley Bomb Mobile Phone Signal Blocker For Schools

Categories Mobile Phone Signal Jammer
Brand Name: GREETWIN
Model Number: GW-VIP JAM6
Certification: SGS, ISO9001
Place of Origin: China
MOQ: 1pcs
Price: Negotiable
Payment Terms: T/T, L/C
Supply Ability: 1000pcs per Month
Delivery Time: 10 Working Days After Received Payment
Packaging Details: Wooden Case with PE Foam
Product Name:: 433MHz Manpack Jammer
Output power: 600W
Operating Temp:: -20℃ to +55℃
Other name: 315MHz Bomb Jammer Trolley Jammer
Jamming range: 50 - 500meters,depend on signal strength of mobile network
Antenna: With Broadband Omni Directional Antenna
Working band: Six Band
Application: VVIP Protection
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

433 MHz Manpack Trolley Bomb Mobile Phone Signal Blocker For Schools

433 MHz Manpack Trolley Bomb Mobile Phone Signal Blocker For Schools


Introduction:


Signal Blocker GW-VIP JAM6 is lightweight manpack cellular jammer, designed for ground troops under the risk of encountering radio controlled improvised explosive devices, known as RCIEDs detonated remotely by cellular devices. Fully weatherproof, and trolly type, has a robust mechanical design, addressing different cellular frequency range requirements simultaneously.
This protects the personnel for moving the unit, protection in places of increasing problem of remote controlled IED deployment. covers 433MHZ, 315MHZ, GSM900, GSM1800, CDMA800, CDMA1900, UMTS-2100(optional) with 50 Watts power output, and it can be customized upon request.

Signal Blocker Technical Specification:


Can customize these frequencies AM, FM Radio, LoJack 173MHz, VHF, UHF, Walkie-talkie, interphone, Wireless Toys , FM Radio, Remote Control, 27MHz, 49MHz, 433MHz,315MHz, 868MHz, 450MHz, iDEN, CDMA, GSM, GPRS, DCS, PCS, AWS,WCDMA,UMTS,3G,4G,LTE 700, LTE 800, LTE 2300, LTE 2600, GPS L1,GPSL2, Galileo, Compass, Glonass, WIFI, Bluetooth, Spy camera, WIMAX, UAV, Drone, 5.8G, etc.


Output interfaceDescriptionShield band of frequencyRF output power
CH1CDMA800851-894 MHz50dBm
CH2WCDMA 3G2110-2170 MHz50dBm
CH3GSM900925-960 MHz50dBm
CH4

GSM1800

/PCS 1900

1805-1880 MHz

/1930-1990 MHz

50dBm
CH5VHF135-174MHz50dBm
CH6UHF400-470MHz50dBm
GPS L1(Optional)1570-1580 MHz
WIFI, 2.4G(Optional)2400-2485 MHz
Power supply: AC220V, DC24V
Total Output Power: 600Watt
Power consumption:1800Watt

Weight: 35Kg

Size(length × wind × high):580×280×410mm

Humidity: 30%-95% Running Temperature: -20℃ to +55℃
Jammer Module Number6
Cooling SystemSystematic Smart Cooling System
System ProtectionVSWR, Over-voltage
Jamming SourceFrequency Scan Technology
Antenna TypeHigh Gain Omni-directional Antennas
Number of Antennas6
Outside Battery (Optional)24V DC
Jamming range: 50-500m according to signal density of mobile network

Signal Blocker Advantages:

  1. High-power multi-band jammer, Frequency Scan technology,
  2. Modular construction for easy maintenance, repair and upgrade.
  3. Jamming up to SIX different jamming modules.
  4. Max 600watts total RF output power.
  5. AC mains or DC power.
  6. Systematic Smart Cooling System.
  7. The general design of the system meets military requirements.
  8. Different frequency bands can be controlled independently by single switches;
  9. Power Amplifiers protection design ensures the working reliability of the device

Signal Blocker Application:

Special Police (S.W.A.T), military security forces, bomb squads, anti-terror units, anti-drug units, Border control units, checkpoint personnel.
