Categories | Side Loader Trailer |
---|---|
Brand Name: | Fudeng |
Model Number: | SDFD1707 side lifter |
Certification: | CE, ISO, CCC, SGS, ADR |
Place of Origin: | Shandong, China |
MOQ: | 1 set |
Payment Terms: | L/C, T/T or negotiate |
Supply Ability: | 600 sets per month |
Delivery Time: | 25-40 days after 30% deposit |
Packaging Details: | Paint and wax spraying |
Material: | Carbon Steel |
Usage: | Transport 20ft And 40ft Container |
Color: | White, Yellow, Red, Green, Blue Customized |
Pattern: | Fudeng Logo Or As Customer's Request |
Suspension: | Mechanical Or Air Suspension |
Capacity: | 16-37 Ton Available |
Conditions: | New |
Curb weight: | 13000kg |
Transport: | by bulk cargo or 20ft container |
Price: | negotiation |
Advantages of side loaders
1. Maximise container movements per day. Containers can be safely transferred to the ground in just minutes, increasing efficiencies and productivity.
Item | Unit | Parameters | |
Lifting Performance | Max. lifting capacity | kg | 37000 |
Max. working range | mm | 4000 | |
Max. stabilizer outreach | mm | 3200 | |
Dimension | Outline dimension of semi-trailer(L×W×H) | mm | 14100×2500×4000 |
Outline dimension of sidelifter(L×W×H) | mm | 1020×2500×2490 | |
Wheel base | mm | 8000+1350+1350 | |
Track(front axle/rear axle) | mm | 1820/1820/1820 | |
Front overhang / Rear overhang | mm | -/2370 | |
Approach angle/Departure angle | ° | -/13 | |
Engine | Model | —— | Kubota V2403-M-DI-E3B-CSL-1 |
Power/rotation speed | kW/r/min | 36.5/2600 | |
Emission standard | —— | Off-road, Euro III |
Designed for faster, safer and more flexible container handling, Fudeng Trailers offer productivity gains. Reduce your transport costs, increase your profits and gain a competitive advantage.
If you are interested in this product, contact us now!
![]() |
