Lab Microcomputer Single - Arm Tensile Testing Machine 100~500mm/min Test Speed

Categories Tensile Testing Machine
Brand Name: HTI
Model Number: HTP-001
Place of Origin: Guangdong,China(Mainland)
MOQ: 1 set
Price: Negotiation
Payment Terms: T/T, L/C, Western Union
Supply Ability: 15 sets per month
Delivery Time: 15 working days
Packaging Details: Wooden box
Power: Electronic
Product Name: Tensile Testing Machine
Dimension: 500*460*1520mm
Test speed: 100~500mm/min
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Lab Microcomputer Single - Arm Tensile Testing Machine 100~500mm/min Test Speed


AC Governor Motor Microcomputer Single-arm Tensile Testing Machine


Description:


This machine can widely apply to a variety of different textile materials and wood, shoes, tires, leather, tannery,rubber tubes, triangular tape, plastic sheeting, plastic sheeting, packaging films, acrylic, FRP, ABS, EVA, PV and other products, semi-or dumbbell-shaped specimens of the tensile strength, elongation, tear, glue focused, tensile stress, peel, shear, the sticky relay of rubber and metal by using different fixtures


Advantages:


1. Speciality in testing equipment

2. Various products to choose from

3. Accept customization

4. Excellent after-sale service


Specifications:

Capacity200KG (2,5,10,20,50,100,200kg for option)
Load accuracy±0.5% of value
DisplayLCD English version, touch key
UnitsKg,lb,N
Data sampling frequency200times/sec
Load solution1/±25000 of max load
Load sensorPull and press sensor(max load)
effective test width150mm
Max stroke1000mm (650mm /800mm for option)
Test speed50-300mm/min stepless speed and 5 steps constant speed
Displacement accuracy±0.5%
Breakpoint ratio0~99%,users could set the right breakpoint time according to different test materials
Safety deviceUp and down stroke limit device
Overload protectionIf 10% over than max load,machine will automatic stop for protection
Result printBuilt in Micro thermal printer
Griptensile fixture 1 set
Machine Size450×500×1400mm
Machine weightApprox 60 Kg
Power220V/50Hz

Standard:


GB,ISO7500/1,JJG475-88,ASTME4,DIN5122,JISB7721/B7733,EN1002-2,BS1610,CNS9471/9470
