| Brand Name: | COMI Lighting |
| Model Number: | B4TA1257(Single Color), B4TA1218(RGB) |
| Certification: | CE, RoHs, SAA, PSE, ETL |
| Place of Origin: | China |
| MOQ: | 10PCS |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 10000pcs per month |
| Delivery Time: | 3~14 working days (Very large order, please inquire separately) |
| Packaging Details: | Inner Box and outer carton |
| Working Voltage: | 24VDC |
| Light Source: | 12pcs 2W or 3W LED |
| Power: | 28.8W(Single Color), 33.6W(RGB) |
| Luminous Flux: | Cool white=2067LM, Warm white=1610LM |
| Material: | Completely stainless steel SUS 316 |
| IP Rating: | IP68 Waterproof |
| Feature: | Dry Land use LED Fountain Light |
| Color: | Single Color, RGB, or R/G/B(4R/4G/4B) |
| Company Info. |
| COMI LIGHTING LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
B4TA1257(Single Color) and B4TA1218(RGB) 12pcs 2W or 3W IP68 Central Ejective Dry Land LED Fountain Lights with Dia. Φ200mm Front Cover
Completely stainless steel SUS 316# housing & accessory
The COMI Lighting FOUNTAIN RING B4TA Or B4TB is conceived for underwater illumination of fountains and water gardens.
● Dimmable, automatic colour change, DMX 512, DALI, 1-10 V
controllable
● Completely stainless steel SUS 316# housing & accessory
● This IP68 luminaire can not be operated out of water for over 15
minutes (cooling).And install underwater less than 1 meter depth.
Material specifications:
| Housing | Stainless Steel 316# Housing |
| Front Cover | Stainless steel 316# |
| Waterproof seal | EPDM gasket |
| Glass | Tempered glass. T=10mm |
| Lens | Optical lens efficiency≥85% |
| Cable gland | IP-68 PG-11 copper and nickel coated |
| Gasket | Glass and housing are silicone sealed |
| LED | Single color LED, Multi RGB color power LED |
| PCB | Excellent heat conductivity aluminum, coefficient of Heat Conductivity≥2.0w/mk |
| Driver | Constant current output Single color LED=1-circuit output RGB 3in1 LED=4-circuit output |
| Application environment | Temperature of water between -20℃~40℃ less than 1 meter depth. |
| Power cable | H07RN-F 2X1.0mm^2 L=3m (for Single color) H07RN-F 4X1.0mm^2 L=3m(for RGB) |
General Information:
| Item No. | Light source | Degree (Θ 1 / 2 ) | Input voltage (V) | Typical operating current (mA) | Typical consumption (w) | Typical luminance (lm) | IK rate |
| B4TA1257 | 12×2W Single Color | 25 | 24VDC | 1200 | 28.8 | Cool white=2067 Warm white=1610 | 09 |
| B4TA1218 | 12×3W RGB Color | 25 | 24VDC | R=400 G=500 B=500 | 33.6 | 726 | 09 |
Dimensional Drawing(Units:mm)
Dimensional Drawing(mm):
Application:
