| Categories | Tapered Button Bits |
|---|---|
| Brand Name: | SOLLROC |
| Model Number: | 32mm-43mm |
| Certification: | SGS |
| Place of Origin: | China |
| MOQ: | 1 set |
| Supply Ability: | 40000 sets per month |
| Delivery Time: | 4 weeks |
| Packaging Details: | Cartons + ply wood case (no plastic) |
| Product name: | Taper Drill Bits |
| Color: | As request |
| Diameter: | 32mm,34mm, 36mm, 38mm, 40mm,42mm |
| Applications: | rock drilling,mining |
| Degree: | 6, 7, 11, 12degree |
| Buttons: | 5-9 buttons |
| Body: | Short and long skirt |
| Company Info. |
| Changsha Sollroc Engineering Equipments Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Tungsten Carbide Rock Drill Taper Button Bits For Hole Drilling
Product specifications:
(1) Taper angle: 4° , 4° 46, 6° , 7° , 11° , 12°
(2) Models: Chisel/cross/button bit
(3) Diameter: 20-45 mm
(4) Button bit shape: Spherical/parabolic
(5) Socket inside diameter: 15/19/22/25mm
| Drill bit diameter | Taper(°) | |
| (mm) | (in) | |
| 28 | 1 3/32 | 6,7 |
| 30 | 1 3/16 | 6,7 |
| 32 | 1 1/4 | 6,7,11,12 |
| 34 | 1 11/32 | 6,7,11,12 |
| 35 | 1 3/8 | 6,7,11,12 |
| 36 | 1 13/32 | 6,7,11,12 |
| 38 | 1 1/2 | 6,7,11,12 |
| 40 | 1 9/16 | 6,7,11,12 |
| 41 | 1 5/8 | 6,7,11,12 |
| 42 | 1 21/32 | 6,7,11,12 |
| 43 | 1 11/16 | 6,7,11,12 |
| 45 | 1 3/4 | 6,7,11,12 |
| 50 | 1 31/32 | 6,7,11,12 |
| 60 | 2 3/8 | 6,7,11,12 |
Tapered cross bit
Used under any rock drilling condition and mainly used for hard or
very hard rock formation because of it's comprehensive
adaptability. Compared with taper chisel bits, taper cross bits
have a better drilling performance because of carbide tips on cross
bits doubled, which means carbides shape are cross type on drill
bits. Taper cross bit is mainly used for hard or very hard rock
formation.
| Description | Diameter | Length | Weight |
| Taper degree a=6 °,7°,11°,12° ; Socket inside d=19,22,25mm | mm | mm | kg |
| 28 | 71 80 | 0.19 | |
| 29 | 71 80 | 0.2 | |
| 30 | 50 67 71 80 | 0.3 | |
| 32 | 50 67 71 80 | 0.3 | |
| 33 | 71 80 | 0.32 | |
| 34 | 67 71 80 | 0.34 | |
| 35 | 67 71 80 | 0.35 | |
| 36 | 71 80 | 0.36 | |
| 38 | 67 71 80 | 0.42 | |
| 40 | 71 80 | 0.43 | |
| 41 | 71 | 0.45 | |
| 42 | 69 80 | 0.46 | |
| 44 | 80 | 0.47 | |
| 45 | 80 | 0.5 |
About US
Main Products:
1-12 inch middle-low/high air pressure DTH hammers & bits
3"-5.5" RC hammer and RC bits
Big hole high air pressure DTH hammer using in water well, oil, gas
and construction drilling
Eccentric overburden drilling Equipment
Hole opener bit
Rock thread bit (R22, R25, R28, R32, R35, R38, T38, T45, T51, ST58,
GT60)
Extension Rod, M/F Rod, M/m Rod, Drift Rod,
Shank adapter, coupling sleeves and all kinds of adapters
We can guarantee all our product:
(1) Direct factory wholesale price, price is cheaper than trading
companies.
(2) Strict Quality Control Department, each piece bit need to be
checked.
(3) Accept custom order. can special make for you.
(4) Focus on the quality.We seek long-term interest.
(5)Welcome small orders, our Min Quantity Order is 1 piece.
Product photos:
|
34mm-43mm Diameter Tapered Button Bits For Geotechnical Borehole Drilling
34mm 7 Buttons Rock Drilling Taper Button Bits for Rock Mining
Rock Drilling Tools Taper Button Drill Bits Tapered Cross Bits
Small Hole Drilling Tapered ToolsTapered Button Bits 32mm to 43mm
H22 Tapered tools Tapered Button Bits 6 7 11 12 degree Taper 32mm to 43mm
Tapered Equipment Tapered Button Bits For Integral Tapered Rod
Tapered Equipment Cross Bit , Carbide Button Bits 28mm - 55mm Long Using Life
Tapered Drilling Tools Tapered Button Bits Drill Bits For Small Hole Drilling
6 7 11 12 Degree Tapered Button Bits For Drifting Drilling Short Or Long Skirt
Self Drilling Tapered Button Bits Thread Button Bits For Anchor Bar Carbide Button Drill Bits
