Mechanical Metal Sheet Automatic High Speed Feeder For Power Press Machine

Categories High Speed Feeder
Brand Name: RUIHUI
Model Number: RF-138NS
Certification: CE,ISO Certification
Place of Origin: Guangdong, China (Mainland)
MOQ: 1 Set
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50 Sets Per Month
Delivery Time: 15 Work Days
Packaging Details: Wooden Box or Vacuum Packing
Model: RF-138NS
Width max. (mm): 130
Length max.(mm): 80
Feeding Thickness (mm): 0~31.6
Feeding line Height(mm): 55~100
Tons Of Presser: 80
Weight (kg): 141
Bearing: Japan NSK
Product name: RF High-speed roll feeder
Function: Feeding material to next process
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Mechanical Metal Sheet Automatic High Speed Feeder For Power Press Machine


Mechanical Metal Sheet Automatic High Speed Feeder For Power Press Machine


Product Application:

This mechanical roller feeder can clamp sheet metal and feed the sheet metal to press machine, for automatic stamping processing.

Main Features:

1. Durative: many project continuous processing is available
2. High Speed: can reach 600 times per minute
3. Fargoing using: to different width and thickness material, only need to adjust feeder to match mold
4. Compact structure, economical using
5. Low malfunction, easy maintenance
6. Feeding precision: depend on revolution and feeding length, normal accuracy is 0.03mm,if guide pin is located, accuracy can reach 0.01mm


Specification:
ModelWidth max.
(mm)
Length max.(mm)Feeding Thickness
(mm)
Feeding line
Height(mm)
Tons Of PresserWeight
(kg)
RF-105NS100500~1.655~1005~2064
RF-205NS200500~1.655~1002087
RF-255NS250500~1.655~1002095
RF-305NS300500~1.655~10040103
RF-355NS350500~1.655~10040111
RF-405NS400500~1.655~10060121
RF-455NS450500~1.655~10080131
RF-138NS130800~1.655~10080141
RF-158NS150800~1.655~100110151
RF-208NS200800~1.660~12020~6084
RF-1310NS1301000~3.570~14040~60125
RF-1510NS1501000~3.570~14040~60142
RF-2010NS2001000~3.570~14040~80155
RF-3010NS3001000~3.570~14060~160180
RF-4010NS4001000~3.570~14080~260200
RF-5010NS5001000~3.570~140110~260220
RF-1515NS1501500~3.570~14040~60143
RF-2015NS2001500~3.570~14040~80156
RF-3015NS3001500~3.570~14020~60181
RF-4015NS4001500~3.570~14080~260201
RF-5015NS5001500~3.570~140110~260221
RF-1520NS1502000~3.570~14040~60146
RF-2020NS2002000~3.570~14040~80159
RF-3020NS3002000~3.570~14060~160184


Q1:What are your equipments certification?
All our items are coming with CE certifications.
Q2:How did your company's quality system work?
"QUALITY IS OUR CULTURE" Our quality is not the best in the world, and the price is not the cheapest. But we can provide you excellent products to defeat your competitors.
Q3:How long is the warranty period of the machine?
We offer free service with a warranty period of one year, If it is operate in reasonable, the machine can be used more than 10 years.
Q4:Are you a trading company or a manufacturer?
Both. RUIHUI MACHINERY one of the market leader for Press Automation Machine more than 15 years.
Q5:Is it possible to be a foreign agent and distributor?
If you are confidence and excellent service for after-sales, then welcome to be our agents or distributors all over the world.
Q6:What's your payment?
T/T,D/P,L/C,Western Union., etc
Q7:What's the delivery?
"TIME IS GOLD" for you and for us, so we have professional team work and production line can make nice quality in short time.
Q8:What kind of industry do your customers mainly do?
Mainly automotive and home appliance,hardware industry customers.
