Durable Residential Solar Power Systems , All In One Home Solar Power System

Categories Residential Solar Power Systems
Brand Name: OEM
Model Number: OEM
Certification: CE ROSH
Place of Origin: CHINA
MOQ: 1unit
Price: Negotiable
Supply Ability: 300 Set/Sets per week
Delivery Time: 20days
Packaging Details: carton
solar panel: 260W solar panel
Load Power (W): 4500W
Inverter: Off grid Pure sine wave
Charging time: 8-10 housr to charge the battery fully
Battery: 12V/12AH SMF lead acid battery
Application: buliding
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Durable Residential Solar Power Systems , All In One Home Solar Power System

On grid 10kw home solar generation power system Residential Solar Power Systems


The Size of Your Solar PV System


The size of your solar system depends on several factors such as how much electricity or hot water or


space heat you use, the size of your roof, how much you're willing to invest, and how much energy you


want to generate. Contact a system designer / installer to determine what type of system fits your needs.


1.1KW Grid Tied Solar System Specification
SOLAR PANEL
Solar panel power Pm12*260WP
Power allowance±3%
Optimized working voltage Vm36.6V
Optimized working current Im7.1A
Open circuit voltage Voc45.1V
Short circuit current Isc7.67A
GRID TIED INVERTER
Inverter Input (DC)
Max. DC power3100W
Max. DC voltage500V
Max. input current8.8A
Number of MPP trackers/Strings per MPP tracker1 1
MPPT voltage range (at rated power)120~425V
Shutdown voltage/Start voltage70/120V
Inverter Output (AC)Inverter Output (AC)
AC nominal power3000W
Max. AC power1000W
Max. AC current5.5A
Nominal AC voltage / range230 / 180~270V
AC grid frequency / range50 / 47~52Hz
Power factor (cosφ)1
Total harmonic distortion (THDi)(at nominal power)<3%
Inverter EfficiencyInverter Efficiency
Max. efficiency96.60%
Euro efficiency95.50%
MPPT efficiency99.90%
Inverter General data
Dimensions (W / H / D)285*385*145mm
Weight [kg]15Kg
Operating temperature range-20~+60 (derating at 45 °C)
Ingress protectionIP65
Topologytransformerless
Internal consumption(night)0
Cooling conceptConvection
Noise (typical)<30 dB
LCD displayBacklight, 16*2 Character LCD
Communication portRS232
SOLAR PANEL MOUNTING(Pitch roof )
Rail2600mm*8pcs
Hook24pcs
Middle clamp20pcs
End clamp8pcs
Connect of rail4pcs
Grounding lug (Optional)10pcs
Earthing clips (Optional)10pcs
ELERTRIC BOX (Optional)AC/DC Circuit Breakers,Lighting arrestors, Electric meter


Solar Panel Modules for Off-Grid Homes


Solar modules essentially work like a car battery charger, except instead of plugging it into the wall, you put


it out directly in the sun. How do solar modules work, and why should you consider an off grid power


systems?


Our Promise to You


Every one of our techs lives with at least some of the products that we feature on our website and in our


catalog. When you order from us, you're not just getting products we believe in, you're getting life-long


support from our team of experts. Your questions will get answered and your needs will be met. It is our


earnest goal to leave you completely satisfied.


We offer FREE custom design service for your alternative energy system as well as FREE after-sale


technical support for the life of the system - it's what has helped make us America's most trusted off-grid


power supplier. Let us work for you!
