25w Poly PV Solar Panels Powering Monitoring Camera Battery Camping Picnic Caravan

Categories PV Solar Panels
Brand Name: OLLIN PV
Model Number: OL-36P-25
Certification: CE
Place of Origin: zhejiang Pr. China
MOQ: 1 piece/unit
Price: Negotiable
Supply Ability: 2300PCS PER WEEK
Delivery Time: 20DAYS
Packaging Details: 2PC per carton,
Material: Polycrystalline silicon
Color: black
dimension: 520*365*18mm
Front Glass: 3.2mm high transmissiontempered glass
Frame: Anodized Aluninium Alloy
Maximum system voltage: DC1000V
Power tolerance: ±5%
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

25w Poly PV Solar Panels Powering Monitoring Camera Battery Camping Picnic Caravan

25w poly PV Solar Panel powering Monitoring camera battery camping picnic caravan RV Boat garden light


Product Specification



Peak Power (Pmax):25W


Short Circuit current (Isc): 1.54A


Open circuit voltage (Voc): 22V


Optimum operating current (Imp): 1.43A


Optimum power voltage (Vmp): 17.5V


Weight:7 lb


Dimension:20.1*14.2*0.8 Inch


All technical data at STC


Test condition:1000W/m², AM1.5,25℃


Application Scope


Courtyard lighting.


Small household lighting system.


Street lighting.


Portable solar power.


All small power electrical devices & small PV system.


Specifications:



Related power25W
Maximum/Peak Voltage(Vmp)17.9V
Open Circuit Voltage(Voc)22.41V
Maximum/Peak Current(Imp)1.4A
Short circuit current (Isc)1.54A
Output Tolerance±3%
Temperate coefficient of Isc(010+/- 0.01) %/℃
Temperate coefficient of Voc- (0.38 +/-0.01) %/℃
Temperate coefficient of power Voc-0.47%/℃
Temperature range-40℃to +80℃
FrameHeavy duty aluminum
Kind of connectionwaterproof junction box, can be customized
Guarantee of power90% within 10 years 80% within 25 years
Kind of glass and its thicknessLow Iron, high transparency tempered glass of 3.2mm
SLA Battery Voltage12V
Size520*365*18


Our Service


1. We have our own factory with professional for solar panel and system over 10 years.

2. We have a strong R&D team.

3. Offering OEM service for your order.

4. Reply within 12 hours.

5. Offering competitive price, good after-sales service.

Company Profile:

We are a professional manufacturer specialized in Solar Panels with more than 8 years of experience. Our

main products include: Mono and Poly Solar Panel, Solar power system, Solar charger controller, Inverters,

Solar LED lights, and so on.

What we can provide: High quality and very competitive price, fast delivery and best service!

A trustable and reliable supplier for your business. We have already exported our products around the world

includes Russian, Middle East, South American, Southeast Asia and so on.

For any details, please don't hesitate to contact me any time!

FAQ

• Are you manufacturer or trading company?

--- we are a manufacturer & system integrator since Jan 2008.

• What kind of certification do you have?

--- Power from 3W to 315W with TUV,IEC61215/IEC61730,CEC,CE,PID,ISO

• What is the warranty of solar panels?

--- 5-year warranty on material and workmanship,90% power output in 10 years,20% in 25 years

• Can you quote me the best price?

---We need more information about your demands, such as the power/material/Qty/etc, then We can

suggest the suitable type and quote the best price for you.
