| Categories | Industrial Inkjet Printer |
|---|---|
| Brand Name: | Perfect Laser |
| Model Number: | PM-100B |
| Certification: | CE / ISO / FDA SGS / TUV |
| Place of Origin: | China |
| MOQ: | 1 Unit |
| Price: | Negotiable |
| Payment Terms: | T/T, L/C, PayPal, Western Union |
| Supply Ability: | 3000 Unit per Month |
| Delivery Time: | 5-7 Working Days |
| Packaging Details: | Sea-Worthy Packing or Air-Worthy Packing |
| Model: | PM-100B |
| Ink value consumption: | 500ml printing (5 * 7 dot matrix digital) about 60,000,000 dot matrix |
| Temperature: | －5℃--45℃ |
| After-Sales Service Provided: | Engineers Service Overseas |
| Origin of Place: | China |
| Plate Type: | Screen Printer |
| Spraying distance: | Trumpet: 3.5mm Medium: 10mm spray nozzle |
| Voltage: | 110V/220V |
| Payment: | T/T |
| Company Info. |
| Perfect Laser (Wuhan) Co.,Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
High Speed Continuous 1-4 Lines Small Character Inkjet Printer For Food Package Pharmaceutical Chemical Industry
(Model:PM-100B)
PM - 100B continuous ink jet printer is a kind of non-contact inkjet printers, spurt the code machine is composed of casing and the nozzle, and
is equipped with electronic components, the ink system and display
power supply, through the connection to the machine on the back of
the flexible pipe nozzle, can be sprayed on most objects on-line
printing data needed for different customers, process simple and
convenient, widely used in pharmaceutical, chemical, food, building
materials, tobacco, ceramics, electronics and other industries, can
be provided to the customers of the highest quality products and
services, free printing time, date, production code, bar code, the
qr code, consumption information, or manufacturer's LOGO, Product
tracking information and other data information.
Usually the printer and production line are installed so that after
the product is sprayed, the printing machine will spray the
required information of the product. At the same time using the
magic eye can ensure that the jet printing and the existence of the
product synchronization.
The ink system supplies the nozzle ink. The ink in the nozzle forms
a continuous flow of ink, which can be recycled in the system. When
ink-jet printing is required, the ink-jet drop used for ink-jet
deflects from the ink flow, and the nozzle is printed on the
product, and the product is in contact with the nozzle during
spraying. The spraying process is controlled by the electronic
components. The spraying printing data is stored in the electronic
components.
1. It can be widely used in pharmaceutical, chemical, food,
building materials, tobacco, ceramics, electronics and other
different industries.
3. Non-contact inkjet printer, convenient and fast to operate, high
quality,
3. A wide range of applications, which can be sprayed on most
objects by time, date, production code, barcode, two-dimensional
code, consumption information, or manufacturer's LOGO, product
tracking information and other data, all the data that need to be
sprayed
| Model | PM-100B |
| Fuselage | Stainless steel 304, surface process |
| Voltage | 220V±20% 50HZ 100VA |
| Pressure | Normal operation under pressure up to 4.48bar, under the fault conditions as high as 6.2bar. |
| Nozzle size | 38*170.1mm |
| Spraying distance | Trumpet: 3.5mm Medium: 10mm spray nozzle |
| Jet printing speed | 2m/s (5 * 7 dot matrix) |
| Jet printing dot matrix | 32 * 140 in any dot matrix, digital, Chinese characters, letters, charts, etc. |
| Spray into the number | 1-4 lines, can be sprayed 34 lines of 1 points high pattern, or four lines of 7 points, or 6 lines of 5 points high character. |
| Character height | Minimum character height of 1.1mm, maximum height of 11.2mm, up to 24 points |
| Meter function | Arbitrary unit meter |
| Adapted ink | Red, black, blue, green, yellow, high adhesion, high temperature, invisible ink, etc. (this machine can not use the pigment ink) |
| Ink value consumption | 500ml printing (5 * 7 dot matrix digital) about 60,000,000 dot matrix |
| Temperature | －5℃--45℃ |
| Humidity | 50--80RH% No dew |
| Spray printing function | Bold characters up to 9 times, characters with rotating function: spray print height, width and delay can be automatically adjustable frequency, date, and time between the word format: fixed and variable text, size, can write character in real time clock function, can jet printing to seconds; USB pattern call / ink jet printer data, backup parameters reduction function / software system upgrade; features a serial number, with hexadecimal counting function a lot number and the counting function, reverse jet printing function, timing functions; date and event format options for a flexible, automatic date calculation. |
| NO | Name | Details | Quantity | Remark |
| 1 | spray-head | Jet nozzle | 1unit | |
Spray chamber, detect very positive and negative high voltage, etc | ||||
| 2 | main pump | Mike pump | 1unit | |
| 3 | filter | The main filter, ink, dilution, on-line filter, buffer filter | 1unit | |
| 4 | power | 220V | 1unit | |
| 5 | Radio-tube | Nozzle valve, ink valve, the valve viscosity, clean the valve, recycle valve | 1unit | |
| 6 | Screen and program Controller | 5.4 inch touch screen | 1unit | |
Motherboard, single-chip microcomputer and the core board | ||||
| 7 | holder | Two-dimensional stet | 1unit | |
| 8 | electronic switch | optical fiber sensors | 1unit | |
| 9 | consumable items | The ink and thinner | 1unit |
1. Prompt deliver at the very day.
2. Sophisticated and professional logistic agent.
3. Well-trained and disciplined packing team.
4. After-sale service:. Any questions or problems after receiving
the product, please feel free to contact us. Problems would be
solved for you immediately.
1. We offer high quality products at competitive price in quick
delivery.
2. 100% custom pass guaranteed.
3. Good after-sale service.
4. Flexible and Untraceable payment terms.
5. Our products have been exported to Germany, Norway, Poland,
Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia,
Japan, Korea, Thailand, Indonesia, Uruguay and many other
countries.
|
