| Categories | Membrane Filter Cartridge |
|---|---|
| Brand Name: | Upick |
| Model Number: | U-DLL004 |
| Certification: | FDA |
| Place of Origin: | China |
| MOQ: | 50PCS |
| Price: | Negotiation |
| Payment Terms: | LC TT PAYPAL |
| Supply Ability: | 12000 PCS per Month |
| Delivery Time: | 15-20 Workdays |
| Packaging Details: | Inner box & Carton |
| Item Name: | soft net PP high flow filter |
| Material: | PP |
| Pore Size: | 5 micron |
| Length: | 20 inch |
| Packing: | inner box |
| Others: | Super service life |
| Company Info. |
| Upick Filtration |
| View Contact Details |
| Product List |
5 micron 40 inch PP high flow filter cartridge for soft net out cage
Description
UPK high flow filter cartridges are plus large diameter pleated cartridge ,significantly reducing the number of cartridges required as well as the housing size.The filter cartridge has flow capacity equal to 10 standard 40 inch long cartridges that would reduce upfront capital costs .
Specification
| Micron rating | 1, 5, 10, 15, 20, 40, 70, 100μm | ||
| Dimension | Outside diameter | 6"(152mm) | |
| Inside diameter | 3.5"(89mm) | ||
| Length | 20", 40", 60" | ||
| Max. Operating temperature | Glass fibers membrane | 121℃ | |
| PP microfiber | 82℃ | ||
| Max. Operating pressure | 0.24Bar@121℃ | ||
| 0.24Bar@82℃ | |||
| Surface area | 24 ft2. (2.2 m2) per 20" element | ||
| 49 f 2. (4.6 m2) per 40" element | |||
| 73 ft2. (6.8 m2) per 60" element | |||
| Maximum flow rates | 20" element up to 40 m3/hr | ||
| 40" element up to 70 m3/hr | |||
| 60"element up to 70 m3/hr | |||
| O-Rings material | EPDM | ||
Application
