| Categories | GPON EPON OLT |
|---|---|
| Brand Name: | OPTFOCUS |
| Model Number: | OFSG3508 |
| Place of Origin: | Shenzhen China |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 5000 pieces per one week |
| Delivery Time: | 5-7 working days |
| Packaging Details: | 540 mm x 367 mm x 100 mm |
| Certification: | CE ISO |
| Wavelength: | Tx 1310nm, Rx 1490nm |
| Product Model: | OFSG3508 |
| Farthest distance: | 20km between OLT and ONU |
| power supply: | DC:-36V～-72V ;Optional dual power supply |
| Dimension: | 442mm*300mm*44mm(length*width*height) |
| Net weight: | 1.84Kg |
| Technical items | Description |
| PORTS | 8*PON interface, SC single-mode/single-fibre,1.25Gbps; |
| 4*10/100/1000Mbps RJ45 | |
| 4*SFP+ | |
| Wavelength | Tx 1310nm, Rx 1490nm |
| Farthest distance | 20km between OLT and ONU |
| Standard | IEEE802.3ah |
| IEEE 802.1D, Spanning Tree | |
| IEEE 802.1Q, VLAN | |
| IEEE 802.1w, RSTP | |
| IEEE 802.3ad, LACP | |
| Ethernet – II, Ethernet-SNAP | |
| IEEE 802.3ad VLAN Stacking( Q in Q) | |
| VLNA | 4K VLAN table items |
| VLAN based on port, MAC, protocol and IP subnet. | |
| port QinQ and flexible QinQ (StackVLAN) | |
| VLAN Swap and VLAN Remark | |
| GVRP | |
| t the addition, deletion and replacement of VLAN based on ONU | |
| business flow. | |
| Management | Support for command line interface (CLI), Console port, |
| maintenance | Telnet and WEB configuration management. |
| IGMPv1/v2/v3.STP/RSTP/MSTP.ACL. | |
| QoS.SNMPv1/v2/v3 | |
| power supply | AC:90～260V,47～63Hz |
| DC:-36V～-72V ;Optional dual power supply | |
| Power consumption | ≤25W |
| Operating condition | Operating temp: -5~+55℃ |
| Operating humidity:10~90%(non-condensed) | |
| Storing condition | Storing temp: -30~+60℃,Storing humidity:10~90%(non-condensed) |
| Dimension | 442mm*300mm*44mm(length*width*height) |
| Net weight | 1.84KgP |
