Green Double Gabion Wire Mesh Knitting Machines / Automatic Hexagonal Wire Mesh Machine

Green Double Gabion Mesh knitting Machine/ automatic hexagonal wire Mesh Machine

Descrition:

The machine is composed with main body, wire-wrapper and net-collector. It has the feature of rational design, simple structure, smooth running, excellent

performance, reliable operation and convenient maintenance.

The main parts, such as drag plate, rack and half-gear are all made of special material with high quality though processing under advanced

technologies.

Main constituent part:c wire tension device and gabion mesh recoiler.

Spare parts: wire pay-off(50 sets), spiral making machine, air compressor, lubrication pump

Main parameter

1. mesh size:100*120mm (or different according your need)
2. width: 4300mm
3. wire diameter: 1.5--3.5mm( PVC wire 2.0--4.5mm)
4. twister number: 3
5. rotate speed: 25r/min
6. power: 22KW
7. output: 195m/hour( 32m per minute)
8. weight: 15T
9. Out side size: main body: 7780*1300*2300mm
10. Wire tension device: 4850*680*800mm

Mesh recoiler: 4880*800*1140mm

Machine Specifications:

Competitive Advantage:

1. The gabion machine has automatic lubricating system and you can set the Lubrication time

2. All the parts of gabion machine are processed by our own factory; no parts were sending to outside to process, so the quality can be ensured.

3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our technician to help install the machines in your country, and also could supply all the spare parts with cost price if customer need.

SUNRICH company start from 2008, from now on we have about 10 years history, our principle is just providing 4G products for customers.

Good material: We just use new materials, never use second hand material. All the important machine parts material are cast steel, cast iron,nodular cast iron. Just use good material then machine will has long life.

Good quality: All machine parts produce by ourselves, we can control all the machine parts material and quality.Our workers have much experience for the machine parts process, we can control the tolerance.

Good technology: We always develop our machine technique according foreign advanced technology and domestic good technology, we try to produce perfect machines for our customer.

Good service: We will provide you good suggestion for what kind of machine is suitable for your production.

Also after machine arrive in your factory, we will send our technician help you installation and debug machine.

If customers need our technician can help you train your workers until they understand.

Our company professionally manufacturers and exports gabion mesh machine, gabion production lines,

and all kinds of gabion products such as gabion boxes, gabion mattresses ,sack gabion and rockfall

netting. our products have been sold in more than 40 countries or regions, such as Malaysia, Thailand,Vietnam,Spain, South Africa, North Africa, Iran, India, Morocco and so on.

We are welcome  foreign and domestic customers to visit our factory. Choose us you will get good suggestions, good technician, good after-sale service.
