Categories | Rotary Selector Switch |
---|---|
Brand Name: | Guangzhou beiwen electric appliance technology co. LTD |
Model Number: | BX1 |
Certification: | CQC,TUV,CB,ROHS.US.CE |
Place of Origin: | Guangzhou, China, |
MOQ: | 10 Pieces |
Price: | negotiable |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 30000+30000+7 |
Delivery Time: | 5-8word dasy |
Packaging Details: | Carton packing. Packing according to the size of the goods or the customer's requirement. |
Max. Current: | 16A |
Max. Voltage: | 250V |
Mechanical Life: | 10000 Cycles |
flammability rating: | UL94v0 |
Operating temperature range: | -40°C to 125°C |
glow-wire test: | 850℃ |
Rated working voltage¤t: | 3/6A250V,10A125V |
1.product detailes:
1.we can provide you with 100 different types rotary switch for your selection.
2.MOQ:1000pcs,mixed order acceptable.
3.10 pcs Free samples available.
4.Various operating force ,height and colour for one switch for your choice
5.OEM professional design.
2
Items | Standard |
Rated working voltage¤t | 10A250V,16A125V |
Contact resistance | less than or equal to 20mΩ |
Insulation resistance | great than or equal to 100mΩ |
Withstand Voltage | 2000Vac |
Operating temperature range | -40°C to 125°C |
Lifetime | 10000 Cycles |
Color | up to your requirement |
Environmental humidity | 45%~95% |
![]() |
