| Categories | Second Hand Solar Panels |
|---|---|
| Brand Name: | Yingli/Jinko |
| Certification: | ISO9001/CE |
| Place of Origin: | China |
| MOQ: | 50 Pieces |
| Price: | Negotiation |
| Payment Terms: | T/T、L/C、West Union |
| Supply Ability: | 5000000 Watt/Watts per Month |
| Delivery Time: | Shipped in 7 days after payment |
| Packaging Details: | In well protected carton or wooden box with pallets. 26pcs per pallet, 380pcs fill into 20GP, 820pcs fill into 40HQ |
| Power: | 260-360W |
| Material: | Polycrystalline Silicon |
| Color: | Blue |
| Condition: | Stock |
| Size: | 1950*990*40mm |
| Max. Power: | 360W |
30 Years Warranty 310w Solar Panel Second Hand Used Solar Panels
Electrical Parameter
| Module | SP100-18P | SP150-18P | SP200-36P | SP250-30P | SP300-36P |
| Rated Maximum Power at STC | 100W | 150W | 200W | 250W | 300W |
| Open Circuit Voltage(Voc) | 21.8V | 21.8V | 44V | 36.8V | 44V |
| Maxinmum Power Voltage(Vmp) | 17.8V | 17.8V | 35.6V | 30.0V | 35.8V |
| Short Circuit Current(Isc) | 6.05A | 9.08A | 6.05A | 9.00A | 9.05A |
| Maxinmum Power Current(Imp) | 5.62A | 8.43A | 5.62A | 8.34A | 8.38A |
| Module Efficiency(%) | 17.2% | 17.2% | 17.2% | 17.2% | 17.2% |
| Operating Temperature | -40°C to 85°C | ||||
| Maximum System Voltage | 1000V(IEC)DC | ||||
| Maximum Series Fuse | 15A | ||||
| Cont | 45±2°C | ||||
| Power Tolerance(W) | -0--+5W | ||||
| Temperature Coefficient of isc(αlsc) | -0.03%/°C | ||||
| Temperature Coefficient of voc(ßvoc) | -0.32%/°C | ||||
| Temperature Coefficient of Pmax(ϒPmp) | -0.42%/°C | ||||
| STC | Irrandiance 1000W/m²,Module temperature 25°C,AM=1.5 | ||||
| Weight (kg) | 8 | 12.5 | 16 | 18.2 | 25 |
| Dimensions(L*W*H) | 1200*540*30 | 1480*670*35 | 1580*808*35 | 1650*990*40 mm | 1950*990*40 |
| Cable Cross Section Size(mm²) | 4 | 4 | 4 | 4 | 4 |
| Cell (mm) | Mono 125*125 | Mono 156*156 | Mono 125*125 | Poly 156*156 | Poly 156*156 |
| No.of Cells and Connections | 36(4*9) | 36(4*9) | 72(6*12) | 60(6*10) | 72(6*12) |
| Junction Box | Ip67,3 diodes | ||||
| Connector | Mc4 Compatible | ||||
| Packaging Configuration | 26 Per Pallet | ||||
|
