Embedded LED Slim Panel Light 180 Degree 12W 18W AC85-265V 4000K 100LM/W
1. 12w 18w LED Slim Panel Light Technical Data:
| Model | AD-ARL-PAL-12w | AD-ARL-PAL-18w |
| Power | 12W | 18W |
| Size | D90*H20mm | D120*H20mm |
| Lumen | 1320LM | 1980LM |
| Cutout | 70mm | 105mm |
| LED Chip | 84LED*SMD2835 | 162LED*SMD2835 |
| Feature | 1. Isolated wide voltage Driver | |
| 2.CRI: ≥80 | ||
| 3.Light Efficary: ≥100LM/W | ||
| 4.warranty: 2 years | ||
| 5.Ordinary color packaging | ||
| 6.Voltage: AC85-265V | ||
| 7. LED Brand: Epistar | ||
| 8. Installation: Recessed Mounted | ||
| 9. Shape: Round Square | ||
2. Frame-less LED Panel Light Advantages:
ADO New product frame-less led panel light is our factory own module. It is different from old led panel light. The difference are:
(1) The front housing is PC material with 88% lighting transmittance, bring soft light.
(2) The emitting lighting is backlit, a round alumium PCB with leds.
(3) Luminous efficiency is up to 110LM/W, 12w lumen is 1320LM, 18w lumen is 1980LM.
(4) Back side housing is aluminum, good heat dissipation.
(5) It is with out Light Guide Plate(LGP), save material cost, makes products more competitive.
3. Packaging:
| Power | Quantity | Carton Size | G.W |
| 12W | 50PCS/CTN | 65*28*20cm | 12KG/CTN |
| 18W | 40PCS/CTN | 38*33*32cm | 9KG/CTN |
| 24W | 30PCS/CTN | 58*44*23cm | 11KG/CTN |
| 30W | 20PCS/CTN | 54*38*28.5cm | 13KG/CTN |
4. LED Panel Light Features:
1. Many shapes: Round / Square
2. Installation: Recessed
3. Many Sizes: 90mm / 145mm / 175mm / 225mm
4. Different Power: 12W / 18W / 22W / 30W
5. CCT: 3000K warm white, 4000K neutral white, 6000K cool white
6. Driver: dimmable and non-dimmable are optional
5. Why Choose ADO LED Slim Panel Light?
1. CE, RoHS, certified LED lights manufacturer
2. Large stock of led chips, led driver and LGP material
3. Short production lead time, fast delivery, discounted DHL/UPS
freight
4. Favorable price as PO qty increase
5. Excellent sales team providing on-time service
6. Strong R&D team with strength to develop new products every
month
7. 6 years LED Lighting experience
8. 3 Year Quality Warranty with good after-sales services
9. Free products industrial design, lighting plan design, Energy saving calculation
10. Your business and private information would be protected strictly .
11. Customized services could be provided.
6. LED Panel Light Application:
Commercial Applications: Showrooms • Apparel Stores • Bookstores • Office Supply and Stationary Stores • Offices • Hallways • Cafeterias • Waiting Rooms and more
Residential Applications: Kitchens • Bathrooms • Rec Rooms • Finished Basement Areas
7. About Customized Services:
1. Slim led panel light back side could be labeled with your logo / brand and company information, this is for free. Also we could laser print your customized information, this need to be paid based on your order quantity. Please inform us when you place order.
2. The inner box could be customized with your box design, white box or colorbox is available. If order quantity is more than 5000pcs, your box design customized service is free, no extra charges. If you don't want box design, we could put label with your logo on the box.
3. The outer carton also could be customized with your logo, or only put label on it.
|
