| Categories | Aluminum End Mill |
|---|---|
| Brand Name: | SUPAL |
| Model Number: | OEM |
| Place of Origin: | Jiangsu,Chiang(Mainland) |
| MOQ: | 5PCS |
| Price: | To be negotiated |
| Payment Terms: | T/T |
| Supply Ability: | 10000000PCS |
| Delivery Time: | 7-15Days |
| Packaging Details: | 1.One piece in a platic pipe, 10 pieces per group. 2.Use the air bubble paper to encase the plastic pipe. 3.Put the goods encased with air bubble paper in the carton. 4.Other packing will be accept according to your needs. |
| Material: | Carbide |
| Diameter: | 1-20mm |
| Overall Length: | 50-150 |
| Flute: | 4 |
| Application: | Metal Working Tool |
| Coating: | AlTiN |
| OEM: | Accept |
| Company Info. |
| Supal (Changzhou) Precision Tools Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Carbiede tapered ball nose end mill two flut taper ball nose end mills tapered
| Product name | countersink tool |
| TRS | >4000 N/mm2 |
| HRA | 91.8-92.4, HRC:45/55/60/65 |
| Grain size | 0.2-0.6μm |
| Helix angle | 30°-45 ° |
| Diameter of cutting edge | 0.2-0.9mm; 1-20mm |
| Size | Diameter 1.0mm-20mm standard and non-standard. |
| Cutting Form | Square,Ball nose, Corner Radius, Taper Flute, etc. |
| Type of flute | 2/3/4/6 |
• Professional Manufacturer for more than 10 yeas experience.
• ISO 9001-2008 Quality Control System .
• 100% virgin tungsten carbide .
• OEM,ODM project accepted .
• Fast delivery time & Convenient Transportation .
| Diameter | CL | OAL | Shank(d) | ||||
| (D) | (L1) | (L2) | |||||
| 1.0 | 3 | 50 | 4 | ||||
| 1.5 | 4 | 50 | 4 | ||||
| 2.0 | 5 | 50 | 4 | ||||
| 2.5 | 6 | 50 | 4 | ||||
| 3.0 | 8 | 50 | 4 | ||||
| 4.0 | 10 | 50 | 4 | ||||
| 5.0 | 13 | 50 | 6 | ||||
| 6.0 | 15 | 50 | 6 | ||||
| 8.0 | 20 | 60 | 8 | ||||
| 10.0 | 25 | 75 | 10 | ||||
| 12.0 | 30 | 75 | 12 | ||||
| 14.0 | 35 | 100 | 14 | ||||
| 16.0 | 35 | 100 | 16 | ||||
| 18.0 | 40 | 100 | 18 | ||||
| 20.0 | 45 | 100 | 20 |
APPLICATION
Its products can be widely used in 3C electronic,mould,automobile,machinery field.etc.
The products are exported to Europe,America,southeast Asia,middle east and Latin America.etc.
|
