UDP IP Output SD Video Encoder COL5141E Digital SD TV MPEG2 H 264 Sdi To Asi Encoder

Digital SD TV MPEG-2 H.264 SDI ASI Encoder UDP IP output Model: COL5141E

Outline

The COL5141E 4CH MPEG-2 H.264 SD ASI IP Encoder is our newest professional SD audio & video encoding and multiplexing device with powerful functionality. It has 4independent channels of unbalanced audio & CVBS video input interfaces or SD-SDI input interface, supporting MPEG-2 and H.264 encoder type. Furthermore, it can support the MPEG-1 Audio layer 2, LC-ACC, HE-AAC, and each channel can support ultra low bit-rate (0.25~15Mbps for H.264 encoding, and 0.5~15Mbps for MPEG-2 encoding). Moreover, it has an ASI input and can multiplex the input TS with the 8(4) encoded SPTS to generate a MPTS output, and users can select the MPTS and 8(4) SPTS through the front panel operation.

Features

• Support H.264,Mpeg2 video encoding
• Support MPEG1 Layer 2,LC-AAC,HE-AAC(v2) audio encoding
• Applicable for one seg(ISDB-T) utilization
• Support PSI/SI editing and inserting
• Supports VBR/CBR video bitrate mode
• Supports MPTS or 4 SPTS UDP IP Output
• Real-time output bit-rate monitoring
• LCD / keyboard and SNMP/web management

Specifications

Digital CATV & IPTV System

Certificates

Exhibition

Colable Electronics co.,ltd

Specialize in Digital TV broadcasting equipment for more than 10 years, and experienced in Digital Cable/Satellite/ Terrestrial tv broadcasting solution and system, If you have any questions and ideas, please no hesitate to contact us!

• Our experience: Standing in digital system solution more than 10 years, with reliable Team.
• Our products: FTA & Descrambler Satellite Decoder, Encoder, Multiplexer, Scrambler, Modulator, Set Top Box etc.
• Payment: Wire Transfer (T/T), Western Union, Paypal, Trade Assurance etc.
• Delivery Date: 2-5 working days
• Our services: Life-long Technical support, remote assistance
• Warranty: 1 year for headend & STB

Please feel free to ask if you have any questions. Welcome !!!

Colable Electronics Co., Ltd

As the outstanding supplier of Digital broadcasting and TV system, Colable electronics is expert in transforming television system from analogue to digital, or building new digital system with most effective way. What we can offer is complete solution of DVB-C/S/T & ISDB-Tb or ATSC from headend to user end with the way of cable, MMDS, MUDS and IP. And our projects relate to different areas, such as city or village coverage, hotel, hospital, university, casino etc.

Colable develops well all the time because it owns one excellent technology and sales team. And the most important point is colable can always provide the most suitable solution to clients from traditional to advanced. Calable's products include: Encrypted or FTA satellite receiver (IRD), MPEG2/4 /H.264 encoder with ASI & IP output (SD and HD), TS multiplexer, scrambler, QAM/QPSK/COFDM/ISDB/ATSC modulator, IP QAM with scrambler (each model support 8 or 16 channels, max 3models for 1U chassis) CAS&SMS, EPG, SD/HD DVB-C/S/T STB, ISDB /ATSC STB, IPTV STB, MMDS /MUDS transmitter and antenna. We also integrate NVOD, PPV and CATV equipments: optical transmitter, receiver, amplifier, tap, splitter, fiber, cable etc to the clients who require.

Colable's perfect products and service win good commend at home and abroad, we will redouble our efforts to meet next brilliance.
