| Categories | Manual Directional Control Valve |
|---|---|
| Place of Origin: | Ningbo China(Mainland) |
| Brand Name: | FLUIDAC or OEM |
| Certification: | ISO9001 |
| Model Number: | 4HV400-15 |
| MOQ: | 5 piece |
| Price: | USD5-- |
| Packaging Details: | Boxes, Cartons,Wooden cases,Pallets |
| Delivery Time: | Within 20 days after receiving payment or deposit |
| Payment Terms: | TT Advance/30% deposit,70% by copy Bill oflading,Western Union,Paypal |
| Supply Ability: | 20000 Pieces Per month |
| Switching Angle: | 90º |
| Body Material: | Aluminum Alloy |
| Function Type: | 3Position 4 Way |
| Motion Pattern: | Direct Acting |
| Port Size: | G1/4 |
| Product: | Manual Directional Control Valve |
| Working Pressure: | 0.15~0.8MPa |
| Company Info. |
| FENGHUA FLUID AUTOMATIC CONTROL CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
G3/8" Manual Directional Control Valve , Pneumatic Hand Switching Valve
4HV Series Three position four way hand switching valve port size G1/4,G3/8,G1/2 e.g 4HV400-15 with 90º switching angle
Quick Detail:
* 4HV Series hand switching valve
* Three position Four Way
* Port Size G1/4,G3/8,G1/2
* Main body mounting and Panel Mounting for option
* Switching angle 90º,sensitive repond acting
* Smooth switching,Long Service Life
Applications:
4HV series hand switching valve manual operated use for fast direction change of anywhere and anytime necessary function required by manual operating,Due to easy and flexible operating,it was widely use in the Pneumatic system
Specifications:
ORDERING CODE | |||
4HV | 200 | 08 | T |
Type | Body Code | Port Size | Mounting Type |
4HV:4HV Series Three position Four Way Hand Switching valve | 200:Body Code for Port size PT1/4" | 08:G1/4" | Blank:Main body mounting |
300:Body Code For Port Size PT3/8" | 10:G3/8" | ||
400:Body Code For Port Size PT1/2" | 15:G1/2" | T:Panel Mounting | |
SPECIFICATION | |||
Model no | 4HV200-08 | 4H300-10 | 4H400-15 |
Working Medium | Compressed 40 Micron Filtered Air | ||
Body Material | Aluminum Alloy | ||
Position And Way Numbers | Three Position Four Way | ||
Port Size | G1/4" | G3/8" | G1/2" |
Effectional sectional Area | 16mm²(CV=0.89) | 33mm²(CV=1.83) | 88mm²(CV=4.89) |
Motion Pattern | Direct Acting | ||
Working Pressure | 0.15~0.8MPa | ||
Switching Angle | 90º | ||
Operating Temperature | 0~70℃ | ||
