Side Mount Plastic Swimming Pool Sand Filters For Pools And Ponds Filtration
Description:
Product features:
* using food grade high density polyethylene (HDPE) material,
corrosion resistance, safer, more environmentally friendly
* the body adopts the integration of thermoforming, makes the body
is stronger, more stable quality, can ensure that is not affected
by the influence of the bad weather, can make the filter and stable
operation for many years
* 6 multi-way valve, combines many functions in one, the only need
to handle gently rotating can easily implement, operation more
simple
* mixed color machine and line clip round base, allowed to rotate
360 degrees, ease of installation
* size optimization design, save the space machine installation and
operation
This product is suitable for: small pool, home swimming pool, SPA
pool, aquarium, waterscape fountain, etc
FEATURES:
Easy to Clean
Suitable for use with Automatic Pool Cleaners
High quality 6 position multi-port valve
Self-sealing barrel unions
Transparent lid for inspection of filtered water
Ring lock design for quick opening and closing, Thereby eliminating
The use of traditional screws
* Use only #20 white silica sand, size range 0.4-0.55mm.
Maximum working pressure: 2.5kg/cm² ; Maximum temperature: 50° C(122° F)
| Model | Pipe size | Filter Area | Design flow | Sand weight | Tank volume | Tank weight | Valve volume | Valve weight |
| (inches) | m2 | m3/h | 0.5-0.8mm (kg) | m3 | kg | m3 | kg | |
| CG450 | 1.5 | 0.16 | 8.0 | 50 | 0.15 | 7.0 | 0.02 | 3 |
| CG500 | 1.5 | 0.23 | 11.5 | 80 | 0.20 | 10.2 | 0.02 | 3 |
| CG650 | 1.5 | 0.32 | 16.0 | 160 | 0.32 | 13.1 | 0.02 | 3 |
| CG700 | 1.5 | 0.40 | 20.0 | 220 | 0.42 | 18.0 | 0.02 | 3 |
Working pressure: 2.5kg/cm2
Testing pressure: 4kg/cm3
Maximum temperature: 43 degree
Size of sand: 0.5-0.8mm
|
