Hotel Security X Ray Baggage Scanner Scanning Image 1024 × 1280 Pixel

Categories X Ray Baggage Scanner
Model Number: AT5030C
Place of Origin: China
Brand Name: SECUSCAN
Certification: CE, ISO
MOQ: 1
Packaging Details: Wooden Packing
Delivery Time: One week when there is stock, One month when no stock.
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100 sets/month
Price: Negotiable
Tunnel size: 503(W)*303(H)mm
Conveyor Speed: 0.22/m
Conveyor Height: 753mm
Max. load: 150kg
Display: color, black and white
Assist function: Explosive and Narcotic Alaming
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Hotel Security X Ray Baggage Scanner Scanning Image 1024 × 1280 Pixel


Hotel Security X Ray Baggage Scanner Scanning Image 1024 × 1280 Pixel


Technology Features:


1. Multi-Energy penetration system

2. New x-ray protection technology

3. Multi-functions image processing system

4. EI-TIP( Threat Image Projection) function

5. Shiny clear images

6. Any selection of the image magnified area

7. Collect the high-speed parallel of detection data

8. Movable machine with integrated structure

9. Sophisticated design with multi-functions operator interface

10.Support JPG&BMP image transformation format to USB


Specifications:


Tunnel Size:

500(W)*300(H)mm

Conveyor Speed:

0.22m/s

Conveyor Max Load:

150kgs

Dose per Inspection:

<2.9 μGy/h

Resolution:

<0.101mm Metal Wire

Penetration:

32mm Steel

Film Safety:

Guarantee ISO1600 Film

X-ray Leakage:

<0.05 μGy/h (at a distance of 5cm From external housing)

Generate direct:

Upward

Generate angle:

80 degree

Anode Voltage:

100-150Kv

Anode power:

0.4 to 0.5mA

Cooling / Duty Cycle:

Oil Cooling /100%

X-ray Sensor:

L-Shaped Photodiode Array (mono-energetic), 12bit Deep

Monitor:

High Resolution Color, LCD Accord, 17 inch

Image Processing:

Edge enhancement, image strengthening, image lightening,

reducing darkening, image returning, image retrieval.

Image Grey Level:

4096

Image Max Resolution:

1024 * 1280 pixel

Image Processing:

24bit for processing real time

Image storage:

Storage 60000 pictures in real time

Zones & Zoom:

1-9 Image regions, 2, 4, 8, 16 Times Enlarge,

Whole screen continuous observation

Operation temperature/Humidity:

0℃-45℃/20%-95%(non-condensing)

Storage Temperature/Humidity:

-20℃-60℃/20%-95%(non-condensing)

Operation Power:

220VAC(±10%)50±3Hz

Power Consumption:

1.0 KW (max), 0.3KW(working)

Noise:

<65db


Applications:


End userRecommend X Ray Baggage Scanner model NO.
Airports, Transport terminalsAT6040; AT6550; AT10080; AT100100
Factories (to find needle in clothing, shoes, bags),AT5030; AT6040; AT6550
Courthouses, Embassies, BuildingsAT5030; AT6040; AT6550
Military installationsAT5030;AT6040; AT6550; AT8065; AT100100
Prisons, Hotels, Schools, Convention centersAT5030; AT6040; AT6550; AT10080
Security checkpoints,Special events locationAT5030; AT6040; AT6550; AT8065; AT10080
